Long Range Wifi Camera Handheld Wireless Barcode Scanner
Products Features:
SD55LG is a smart handheld barcode scanner and it's specially designed for logistics industry, with high performance of Android 8.1 OS and MT6763 Octa-core processor.
Large screen of 5.5'' HD 720 x 1440, offers better visual experience. Large memory 4G+32G(extensive 128G) is totally available to meet huge volume data storage.
With 13MP autofocus camera, 4G LTE, dual wifi 802.11 a/b/g/n, Bluetooth, and 4G LTE, distinct configuration in all aspects. 1D or 2D barcode scanner options.
Products Specification:
| SD55LG Basic Parameters |
| OS | Android 8.1 |
| CPU | Octa-Core 2.0GHz |
| RAM | 4GB |
| ROM | 32GB |
| Expansion | Micro SD (TF) card slot up to 128GB |
| Keypad | 5 side buttons,2 volume buttons,2 function buttons(1 left and right),1 power button |
| Audio | 1609 Dual speakers,waterproof design,Dual silicon mic noise reduction |
| Notification | Sound/vibration/LED prompt |
| Dimentions | 150mm*72.5mm*15mm |
| Weight( with battery) | 200g |
| Camera |
| Camera | Rear camera 13MP AF(16MP PDAF option)；Front Camera 5MP FF |
| Focus mode | Autofocus ; Front focus |
| Flash | Support single color LED flash |
| Display |
| Display | 5.5 Inch Full Screen |
| Resolution | 720*1440 |
| Touch Panel | 5-point capacitive touch screen |
| Power |
| Battery | large-capacity unremovable Li-ion battery 4500mAh |
| Charging | PE fast charging, fully charged time< 4 hours
Wireless charging QI standard, 5w or 10w |
| Interface | support USB-TypeC, support fast charge, support OTG |
| Communication |
| GPS | BT4.0 BLE |
| WLAN | WiFi 802.11 a/b/g/n 2.4G 5G |
| WWAN | FDD-LTE B1/B3/B5/B7 or B1/B4/B8/B13
TDD-LTE B38/B39//B40/B41
TDSCDMA B34/B39
WCDMA B1/B2/B5/B8
GSM B2/B3/B5/B8
CDMA1x/CDMA2000 BC0 |
| GPS | GPS,GLONASS,BeiDou,AGPS,option UBLOX8030 |
| Performance |
| Operation Temperature | -20℃ ~60℃ |
| Storage Temperature | -30℃ ~+80℃ |
| Humidity | 5%~95%(No condensation) |
| Sealing | IP65 |
| Sealing | In the operating range, 6 sides can withstand the impact of 1.5 meters drop to the concrete floor |
| Tumble Test | 6 contact surfaces rolling for 1000 times/ 0.5M |
| ESD | ±15kV Air Discharge, ±8kV Contact Discharge |
| Certificate | CCC,CTA,CE,FCC |
| Extensibility |
| NFC RFID Reader | NFC (PN548) Support NFC Reader/writer, ISO14443-A/B/F, ISO18092, FeliCa, MIFARE, ISO15693 |
| Barcode Scanner | 1D/2D: Honeywell N6603 or Speedata SD5670 |
| PSAM | support |
| Sensor | geomagnetism, acceleration, light perception distance,berometer(optional), gyroscope (optional) |
Products Details
Speedata Services
As a listed company from china manufacturer, we support you:
Completely Free SDK and technical support for you.
ODM/OEM customization services according to your needs.
13 months warranty for your devices and other parts. and 6 months for the batteries. Exend warranty,it'll cost 0.5% for each per year.
Free maintenance of the devices and part of accessories replacement in the warranty .if out of the warranty, you'll have to pay the basic cost for them.
FAQ
Question 1: What's your MOQ?
The MOQ of barcode scanner handheld PDA is 1 piece.
Question 2: How long is the delivery time?
The delivery time of barcode scanner goods is different from quantities:
If 1~100 pcs, It's about 5--10 working days;
If 100~500 pcs, it's about 10--20 working days;
If More than 500 pcs, It's about 20-30 working days.
Question 3: Would you like to supply 1 sample for testing?
Yes, Of course. We can provide 1 sample Terminal PDA for your testing.
Question 4: What's the total price for 1 sample?
As a manufacturer of barcode scanner terminal PDA,the more you buy, the cheaper it'll be.
The sample price is a little bit higher than the common wholesale price excluding the freight fee.
Question 5: Are you a manufacturer of Handheld PDA?
Yes, we are a R&D orientation China Listed Company, mainly producing industrial PDA Terminal Hardware and as a software solutions supplier with over 8 years' OEM/ODM experience. We are also cooperating with Foxconn Factory.
Question 6: What kind of services do you support ?
We provide you Free SDK and Technical Support for your Barcode Scanner.
We also provide ODM/OEM Customization Services based to your demands.
We support 13 months Warranty for all the device and 6 months for the batteries. Exend warranty, it costs 10% at the first year, and 15% for the second year.
Question 7: What's for payment term and delivery term ?
It's generally 30%-100% TT in advance for all orders. Meanwhile, Paypal or West Union is acceptable.
FOB Shenzhen as Trade Term.
Question 8: Who are your customers?
Our products have been sold to worldwide,especially market in South/North America, Europe, Asia, Africa Mid-east, etc.
The market share is increasing quickly every year and we get more and more positive feedbacks from our customers.
